Trailer 9″ Brake Drum

HHD

These trailer 9″ brake drums are suited for axles that use mechanical and hydraulic brakes. Each brake drum comes with pre-pressed cups and all fittings are included.

Description

The trailer 9″ brake drum is one of the most common styles of hubs used on medium to heavy duty trailers with mechanical or hydraulic brakes. Each drum comes complete with the bearings, seal, dust cap and nuts you need to safely replace the hubs on your trailer. Designed for everyday use, the LM style of bearings are usually suitable for trailers with 39mm round or 40mm square axles, while the S/LINE style of bearings are typically used on 45mm and selected 50mm axles. If you aren’t sure what bearing style or stud pattern you have please view the downloadable resource pdf attached or contact on of our friendly staff. Sant Auto 9″ Drums are 9″ x 1.75″

Advantages

Pick your stud pattern
Pick your bearing style
Pre-pressed bearing cups
Fittings included
Natural finish
SG casted iron

What’s Included

1 x Trailer Disc Hub
1 x Inner Cup & Cone
1 x Outer Cup & Cone
1 x Oil Seal
1 x 3/4″ Dust Cap
Wheel Nuts to suit

Note the “Bare” option has no fittings or cups.

Additional information

Stud pattern	Commodore, F100 Ford, Ford, Holden HT, Landcruiser 5 Stud, Landcruiser 6 Stud, Nissan Navara
Bearing type	Bare, LM, S/Line

STUD PATTERN

STUD PATTERN	STUD PCD	STUD DISTANCE	COMMON STUD SIZE
FORD	5 x 114.3mm	67.18mm	1/2"
COMMODORE	5 x 120mm	70.53mm	7/16"
HQ HOLDEN	5 x 120.65mm	70.91mm	7/16"
HT HOLDEN	5 x 108mm	63.95mm	7/16"
LANDCRUISER/NISSAN	6 x 139.7mm	69.85mm	1/2"
LANDCRUISER 100 SERIES	5 x 150mm	88.20mm	9/16"
GEMINI	4 x 100mm	70.71mm	7/16"
DATSUN	4 x 114.3mm	80.80mm	7/16"
